Product Details
Place of Origin: Guangdong, China
Brand Name: Longyuan
Certification: CE ROHS ISO9000
Model Number: LY-8817
Payment & Shipping Terms
Minimum Order Quantity: 100 pieces
Price: $3.15/pieces 100-999 pieces
Packaging Details: Carton:100PCS/CTN or Customized packaging according to customer requirements.
Delivery Time: 5-15work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union
Supply Ability: 20000 Piece/Pieces per Day
Rated Voltage: |
DC24V |
Max Power: |
24W |
Current: |
1A |
Lock Shell Material: |
SPCC |
Lock Body Size: |
80.6mmx55.6mmx14mm |
Work Temperature: |
-40℃ To +80℃ |
Weight With Hook: |
192g |
Salt Spray Testing: |
≥48hours |
Usage: |
Supermarket Self-service Cabinet,parcel Cabinet,vending Machine Etc |
Port: |
Shenzhen |
Rated Voltage: |
DC24V |
Max Power: |
24W |
Current: |
1A |
Lock Shell Material: |
SPCC |
Lock Body Size: |
80.6mmx55.6mmx14mm |
Work Temperature: |
-40℃ To +80℃ |
Weight With Hook: |
192g |
Salt Spray Testing: |
≥48hours |
Usage: |
Supermarket Self-service Cabinet,parcel Cabinet,vending Machine Etc |
Port: |
Shenzhen |
Product Description
1.Model: LY-8817
2. Connector: SM-2Y,SMY-2A
3. Elasticity of Opening door: ≥2.3kg ±15%
4.Lock latch height: standard 29mm(available customized/accept custom)
5.Max bearing force of the lock latch:≥600N
Customer Service
1. Your inquiry related to our products or price will be replied in 24hrs.
2. Keep informing our customer production process and help arrange quality checking in the factory if necessary.
3. One-year warranty to our locks.
4. Buyer can dispatch technician to our factory for free training before delivery.
Principle
It is based on 51 series single-chip microcomputer (AT89051) and equipped with corresponding hardware circuit to complete password setting, storage, identification and display, drive electromagnetic actuator and detect its driving current value, receive alarm signal sent by sensor, send data and other functions. The single-chip microcomputer receives the typed code and compares it with the password stored in the EEPROM. If the password is correct, the electromagnetic actuator will be driven to unlock; if the password is incorrect, the operator will be allowed to re-enter the password for up to three times; If it is not correct, the single-chip microcomputer will send an alarm to the intelligent monitor through the communication line.
Product Description
|
Product Name
|
Smart Hidden Keyless Electronic lock
|
|
Model
|
LY-8817
|
|
Brand
|
Longyuan Lock
|
|
Size
|
80.6mmx55.6mmx14mm
|
|
Weight with lock hook
|
192g
|
|
Material of lock body
|
SPCC
|
|
Material of lock tongue
|
Powder Metallurgy
|
|
Surface treatment
|
Galvanized
|
|
Cable outer leakage length
|
170mm(accept customized)
|
|
Working voltage
|
DC24V (Voltage customized)
|
|
Working current
|
1A
|
|
Min Unlock Voltage
|
19V
|
|
Maximum power
|
24W
|
|
Manner of working
|
Open after power on
|
|
Reaction time
|
0.3sec
|
|
Blackout interval
|
>5sec
|
|
Working temperature
|
-40℃ to +80℃
|
|
Working humidity
|
95%
|
|
Working life
|
more than 100,000 times
|
|
Sample
|
Available
|
|
OEM
|
Accepted
|
|
Signal detection/switch(open/close)
|
Open/ Close Feedback for option
|
|
Certification
|
CE,ISO9001, RoHS
|
|
Warranty
|
1year
|
Packing List
Standard package: Carton box package, 50pcs/layer, 100pcs/carton.
Carton size:370mmx270mmx140mm.
Lock latch: 1000pcs/carton
Mounting screws: 9000pcs/carton
Customized package also available.
